BluePrint Engines Chev 454 SBC Pro Series Stroker Engine 563hp # PS4541CTC1

• HP & Torque: 563 HP / 545 FT LBS
  Compression Ratio: 10.0:1
  Aluminum Heads
  Hydraulic Roller Cam
  Forged Crank
  Forged Pistons

BLOCK:

• NEW BluePrint Cast Iron Block
  Manufactured and Machined in the USA!
  4-Bolt Main
  4.250" Bore
  2-Piece Rear Main Seal
  Mech fuel pump provision: Yes
  Passenger Side Dipstick

• Drilled and tapped for clutch linkage

ROTATING ASSEMBLY:

• New BluePrint Forged Crankshaft
  4.000" Stroke
  Forged 6.000" connecting rods
  Forged Pistons
  Internal Front/ Internal Rear

CYLINDER HEADS:

• BluePrint Aluminum Cylinder Heads - HP8103
  64cc chamber
  2.08" intake/1.60" exhaust valves
  220cc intake/67cc exhaust runners

CAM SPECS:

• Cam Type: Roller
  .638 Intake .622 Exhaust
  251 Intake / 259 Exhaust duration
  @ .050 - 114 degree lobe separation

IGNITION TIMING:

ALSO INCLUDES:

• MSD Pro Billet distributor
  950 CFM CARBURETOR
  Aluminum intake manifold
  Valve covers, oil pan and timing cover
  Harmonic balancer
  Dyno test results shipped with engine
